48V 500W Pedal Assist Electric Bike , Bicycle With Motor Assisted Pedal Power

China 48V 500W Pedal Assist Electric Bike , Bicycle With Motor Assisted Pedal Power supplier

Large Image :  48V 500W Pedal Assist Electric Bike , Bicycle With Motor Assisted Pedal Power

Product Details:

Place of Origin: CHINA
Brand Name: DREAM WHEEL
Certification: CE
Model Number: EBS611

Payment & Shipping Terms:

Minimum Order Quantity: 10 units
Price: USD
Packaging Details: 7 layer strong carton plus foam protector ; 48pcs in 1x20"; 140pcs in 1x40"HQ
Delivery Time: 20-30days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2000 units per month
Contact Now
Detailed Product Description
Motor: 48V Brushless Hub Motor Rated Power: 500W
Speed: 25-38m/h Colours: The Colours Can Be Made By Order
Controller: 48V 25A Intelligent Climb Ability: 15 Degree
Battery: 48V 12Ah Removable Battery PAS: Yes
High Light:

48V 500W Pedal Assist Electric Bike

,

38m/h Pedal Assist Electric Bike

,

48v 12ah bicycle with motor assisted pedal power

European Standard 500w Motor Pedal Assist Electric Bike 48v 12ah Removable Battery



Quick Details



1. Motor power: 48V 500W rear brushless motor

2. Battery: 48V 12Ah removable battery

3. Tire size: 16”X 2.5

4. Brake system: Disc brake for front wheel

5. Pedals assisted system and Throttle: Yes

6. Max Speed: 38m/h



Product Descriptions



EBS611 can be made with green, blue, black, yellow, white and grey colours. 48V 500W rear hub motor, with PAS, can get  38km/h max speed.



Yes, the battery can be take out of the bike, charge in the room.



Specifications



Model number

EBS611

Motor

48V 500W rear brushless motor

Battery

48V 12Ah,  removable

Charge time

4-8h

Charger

 48V 2A, plug can be customized

Controller

 48V 25A

Speed

25-38Km/h

Speed mode

Single level

Driving distance

35-40km

Weight

65Kgs

Packing dimension

1480x350x860mm

Package

90% completed, one piece per carton

Panel/speedometer

Normal display

Driving mode

Pedals assisted and Throttle

Alarm system

Remote alarm

Wheel

16”

Tire

16”x2.5,  CST tire

Chain

Normal

Frame

Paint with electrophoretic coating

Fork

with suspension

Shift lever

--

Rear derailleur

--

Front brake

Disc Brake

Rear brake

Drum Brake

Brake levers

Aluminum

Rims

Aluminum alloy

Spokes

--

Pedals

Normal

Chainwheel

28T

Cranks

steel

Freewheel

16T

Handlebar

 Steel

Stem

--

Grip

136MM

Seat

Lengthen, black

Seat tube

--

Headlamp

Normal

Fenders

Plastics

Wheel base

--

Min ground clearance

--

Saddle ground clearance

--

Handlebar ground clearance

--

Licence requirement

No



Pictures Show



48V 500W Pedal Assist Electric Bike , Bicycle With Motor Assisted Pedal Power 0



48V 500W Pedal Assist Electric Bike , Bicycle With Motor Assisted Pedal Power 1
