Detailed Product Description
Package Size: 173x25x78cm Gears: 7 Speed
Color: Black, White, Red, Blue Tire: 27.5" MTB Tire
Battery: 800 Times Recycle Speed: 25km/h European Standard
High Light:

27.5in Electric Mountain Bicycle

,

Electric Mountain Bicycle 36V 350W

,

36V 10.4Ah battery operated mountain bikes

7 Speed Electric Mountain Bikes 36V 350W 27.5” Aluminum Frame Samsung Battery





Quick Details



1.  Motor power: 36V 350W BAFANG rear GEAR motor

2.  Frame material: Aluminum alloy 6061

3.  Lithium battery: 36V 10.4Ah Samsung cells

4.  Certification: EN15194

5.  Wheel size: 27.5"

6.  Brake system: Tektro Hydraulic Disc brake for both wheels

7.  Derailleur system: Shimano RD-TX55

8.  Pedals assisted system: Yes.  throttle can be optional



Product Descriptions



This electric mountain bike is our new Design model in 2015, class as High end product series. This is an exciting bike, combine many high end parts, like TEKTRO Hydraulic Disc brake, Shimano Derailleur, BAFANG rear Gear hub motor, and RST hydraulic suspension.   At present, main market is Europe and America.



This electric bike have a beautifully integrated Lithium-ion battery pack. It’s easy to operate this mountain electric bike, with two steps. First, need turn ignition key in ON status, and second step, press button on handlebar is ok.  There are offer 5 drive modes, like normal, eco, sports on LCD display. We must say, this the newest display system work very smoothly, will be best partner for the bike.



Components



1.  BAFANG rear gear motor, China famous electric bike motor supplier. This rear-drive motor, which is compatible with the disc brake, has a rated power of 250-500W, a reduction ratio of 1: 5 and a maximum torque of 48 N.m, providing ideal power for vehicles. Strong and efficient, this motor, working together with a cassette speed change mechanism, greatly enhances riding comfort and is suitable for touring bikes, commuter bikes and mountain bikes.



2.  TEKTRO Hydraulic disc brake, produce with high efficient brake performance, can stop quickly no matter when you need.



3.  RST fork, mountain bike series, made with oil pressure system, mechanical lock-out, adjustable pressure. This is  one reliable suspension solution.



4.  Know more about details, check the below details.



Specifications



Model number

EBS320

Motor

BAFANG, 36V 350W rear GEAR motor

Battery

36V 10.4Ah lithium, SAMSUNG cells

Charge time

4-8h

Charger

110-240V, 36V 2A, plug can be customized

Controller

 36V 14A

Speed

32Km/h

Driving distance

50-60km by PAS

Weight

26Kgs

Packing dimension

1720x250x780mm

Panel/speedometer

 LCD display

Wheel

27.5”

Tire

27.5x1.95, KENDA

Chain

1/2*3/32*116L, KMC rust-proof

Frame

Aluminum alloy 6061

Fork

travel 100MM, 28.6*25.4*210L*30*100MM

Shift lever

Shimano 7 speed

Rear derailleur

Shimano RD-TX55

Front brake

TEKTRO Hydraulic Disc Brake

Rear brake

TEKTRO Hydraulic Disc Brake

Brake levers

 TEKTRO

Rims

Aluminum alloy,27.5*1.75*36H*13G

Spokes

Front:13GX256/258; Rear:13GX220/222;

Pedals

Wellgo, with ball

Chainwheel

1/2*3/32*44T*170L

Cranks

Aluminum, 170L

Freewheel

14-28T, 7 level

Handlebar

ZOOM Aluminum, W620x2.0T

Stem

ZOOM Aluminum, adjustable

Grip

22.4/136MM, Black

Seat

KS8016, Gel

Seat tube

Aluminum with suspension, 27.2*300*2.0T

Lamp

LED for front

Wheel base

1260mm

Min ground clearance

110mm

Saddle ground clearance

Max:990mm; Min:790mm

Handlebar ground clearance

1100mm

Licence requirement

NO
