Product Details:
Payment & Shipping Terms:
|
| Wheel: | 26" | Motor Power: | 36V 350w |
|---|---|---|---|
| Speed: | 32km/h | Battery Recycle: | 800 Times |
| Battery: | 36V 10.4Ah Lithium Battery | Panel: | LCD Style |
| High Light: | 32km/H electric ebike conversion kits,350w ebike conversion kit with battery,OEM 26 electric bike conversion kit |
||
32Km / H Electric Bike Conversion Kits , Bicycle Motors Kits With 26” Wheel
Quick Details
1. Motor power: 36V 350W Bafang rear Gear motor
2. Lithium battery: 36V 10.4Ah Samsung cells
3. Wheel size: 26”
4. Brake system: Disc brake
5. Pedals assisted system throttle: Yes
Product Descriptions
This conversion kits, without tire and disc brake, and the battery box can be fixed on frame tube.
The motor use 350W power, max speed can reach 32km/h.
Components
1 x 36V 350W rear Gear motor
1 x 26”aluminum alloy rim
1 x Shimano 6 speed freewheel
1 x set 13G stainless steel spoke
1 x 36V 10.4Ah lithium battery
1 x 36V 350W brushless controller with box
1 x throttle
1 x pair Aluminum brake lever
1 x LCD version panel
Specifications
|
Model number |
EBSCK809 |
|
Motor |
BAFANG, 36V 350W rear GEAR motor |
|
Battery |
36V 10.4Ah lithium, SAMSUNG cells |
|
Rear carrier |
Aluminum alloy |
|
Charge time |
4-6h |
|
Charger |
110-240V, 36V 2A, plug can be customized |
|
Controller |
36V 18A |
|
Speed |
32Km/h |
|
Driving distance |
45-55km by PAS |
|
Weight |
14Kgs |
|
Packing dimension |
730x600x210mm |
|
Panel/speedometer |
LCD version |
|
Wheel |
26" |
|
Tire |
-- |
|
Rear brake |
-- |
|
Brake levers |
Aluminum |
|
Rims |
Aluminum alloy,26”*1.75*36H*13G |
|
Spokes |
Rear: 13GX207/209; |
|
Freewheel |
Shimano 6 level |
|
Throttle and grip |
Normal |
|
PAS |
-- |
Pictures Show
